Dymonic 100

TECHNICAL DATA SHEET

DYMONIC® 100

High-Performance, High- Movement, Single-Component, Polyurethane Sealant

PRODUCT DESCRIPTION

Dymonic® 100 is a single-component, medium-modulus, non-sag polyurethane sealant. Dymonic 100 offers a high- performance, high-movement, durable, flexible seal that performs excellently in moving joints and exhibits tenacious adhesion to substrates once fully cured.

BASIC USES

Typical applications for Dymonic 100 include expansion and control joints, precast concrete panel joints, perimeter caulking (windows, doors, and panels), aluminum, masonry, and vinyl siding. Dymonic 100 is also an excellent choice as a fluid applied flashing material in rough opening perimeters for fenestration/window, door and curtain wall applications. Dymonic 100 is suitable for water immersion applications and will not out gas.

FEATURES & BENEFITS

Dymonic 100 has been formulated with an innovative polymer technology, similar to TREMproof® 250GC and Vulkem® 45SSL, that allows it to be highly versatile and grants its unique capability to adhere to damp or green concrete without outgassing. The skin time of Dymonic 100 is 2 hours and the tack-free time is 6 to 8 hours. This significantly reduces dirt attraction and improves the overall asthetic look.

Dymonic 100 has a movememnt capability of +100/-50% in typical field conditions with excellent performance in moving joints. The formula is low-VOC and UV-stable, meaning Dymonic 100 will not crack, craze, or yellow under extreme UV exposure. Additionally, Dymonic 100 is jet fuel-resistant and compatible with many common construction substrates.

• Compatible with and can be coated over with Tremco's Vulkem Deck Coatings, ExoAir® Air Barrier products and the cold, fluid-applied TREMproof® line of below-grade waterproofing products

• Accepted for use over Nudura Insulated Concrete Forms (ICF)

  There are 21 standard color options available for Dymonic 100, with the option of painting over the sealant. Dymonic 100 meets or exceeds the requirements of the following specifications:

• ASTM C920 Type S, Grade NS, Class 50, Use NT, T, M, A, O, I

• U.S. Federal Specification TT-S-00230C, Class A, Type II

• CAN/CGSB-19,13-M87

• International Code Council (ICC) Section R703.8 Flashing

• AAMA 714-15 Specification for Liquid-Applied Flashing

• NFPA 285 Listed Component

  Accepted fire rated systems: FF-D-1186, FW-D-1117, HW-D-1122, WW-D-1200, and BW-S-0006

  AVAILABILITY

  Immediately available from your local Tremco Sales Representative, Tremco Distributor, or Tremco Warehouse in 10.1 oz (300 mL) cartridges and 20 oz (600 mL) sausages.

  COLORS

  Available in Almond, Aluminum Stone, Anodized Aluminum, Beige, Black, Bronze, Buff, Dark Bronze, Gray, Gray Stone, Hartford Green, Ivory, Light Bronze, Limestone, Natural Clay, Off White, Precast White, Redwood Tan, Sandalwood, Stone, and White.

  LIMITATIONS

  Use with adequate ventilation. Always utilize the accompanying SDS for information on Personal Protective Equipment (PPE) and Health Hazards. Not recommended for use in chlorinated, potable, heavy or waste water. Although Dymonic 100 is paintable, this does not imply adhesion to and compatibility with all paints. Consult Tremco Technical Bulletin No. S-09-05 or Tremco Technical Services for more information.

  WARRANTY

  A repair or replacement warranty is available on all Tremco products. Visit https://www.tremcosealants.com/warranties/ for details.

TYPICAL PHYSICAL PROPERTIES

PROPERTY

Rheological Properties

Hardness Properties

Weight Loss

Skin Time

Tack Free Time

Stain and Color Change

Adhesion to Concrete

Adhesion to Concrete After Immersion

Adhesion to Green Concrete

Adhesion to Damp Concrete

Effects of Accelerated Aging

Movement Capability

Movement Capability

Tensile Strength

% Elongation

Modulus at 100%

Tear Strength

TEST METHOD

ASTM C639
ASTM C661
ASTM C1246
ASTM C679
73.4°F (23°C) 50% RH ASTM C510

ASTM C794 ASTM C794 ASTM C794 ASTM C794 ASTM C793 ASTM C719 ASTM C719 ASTM D412 ASTM D412 ASTM D412 ASTM D412

TYPICAL RESULTS

Non-sag (NS), 0” of sag in channel 40 ± 5
Pass
2 to 3 hr

6 to 8 hr Pass
35 pli 30 pli >25 pli >20 pli Pass

± 50% +100/-50% 350 to 450 psi 800 to 900% 75 to 85 psi 65 to 75 psi

(Modified)

TYPICAL PHYSICAL PROPERTIES

Fungal Resistance

Service Temperature

Application Temperature

Smoke Development, Fire Spread

Smoke Development, Fire Spread

Fire Resistance of Assembly

Crack Bridging

Nail Seal Ability

ASTM G21-15

ASTM E84
CAN S102
NFPA 285
ASTM C1305
ASTM D1970 Section 7.9

Fungal Resistance = 0, No Growth -40 to 180 °F (-40 to 82 °C)
40 to 100 °F (4 to 37 °C) *
5, 5

10, 10 Pass Pass Pass

*For temperatures below 40 °F, please refer to the Technical Bulletin, Cold Temperature Sealant Application Recommendations.

Please refer to our website at www.tremcosealants.com for the most up-to-date Product Data Sheets.

NOTE: All Tremco Safety Data Sheets (SDS) are in alignment with the Globally Harmonized System of Classification and Labelling of Chemicals (GHS) requirements.

D100-DS/0724
