Proglaze SSG
PRODUCT DESCRIPTION Proglaze® SSG is a single-component, neutral-cure, high-modulus silicone sealant ideal for a wide variety of glazing applications that call for fast through-cure and exceptional tensile strength. BASIC USES Proglaze SSG is designed to meet the stringent performance needs for both 2- and 4-sided structural* and protective glazing, including cap, heel, or toe bead. Whether it is a unitized curtain wall manufactured in-plant or a field-glazed project, Proglaze SSG offers fast through cure and exceptional tensile strength to meet the most stringent building codes. *All structural glazing applications must be reviewed and approved by Tremco Technical Services. FEATURES & BENEFITS The high modulus of Proglaze SSG produces a tough, flexible rubber cure that creates a tenacious, watertight seal. This sealant is easy to apply with conventional caulking equipment and comes ready to use with no mixing required for immediate application. Proglaze SSG provides the excellent adhesion, fast through-cure, and exceptional tensile strength & flexibility that is critical to withstanding wind cycle loads and missile impacts. It has been impact/hurricane tested to the industry's most stringent performance standards, including the Miami/Dade Protocol. Additionally, Proglaze SSG has been successfully tested as a structural anchor in retrofit Blast Film applications. Proglaze SSG meets or exceeds the following specifications: • ASTM C 920 Type S, Grade NS. Class 25, Use NT, G, A • CAN/CGSB-19.13-M87 • U.S. Federal Specification TT-S-00230C (COM-NBS) Class A, Type II • U.S. Federal Specification TT-S-001543A (COM-NBS) Class A • ASTM C1184 Use G and O (aluminum) • AAMA 802.3-10, Type I The Greenguard Gold certification on Proglaze SSG ensures safety for use in the most sensitive indoor environments including hospitals and schools. AVAILABILITY Immediately available from your local Tremco Sales Representative, Tremco Distributor, or Tremco Warehouse in 10.1 oz (300 mL) cartridges, 20 oz (600 mL) sausages, 4.5 gal (17 L) pails, and 50 gal (189 L) drums. COLORS Proglaze SSG is available in Black and White. All colors are not available in all packages. Some colors may require a minimum quantity. Contact Tremco Customer Service for more information. TECHNICAL DATA SHEET PROGLAZE® SSG Single-Component, Neutral-Cure, Silicone Sealant for Structural Glazing LIMITATIONS Proglaze SSG should not be applied to damp or contaminated surfaces. For good adhesion, the joint interface must be sound, clean, and dry. Proglaze SSG is not intended for continuous water immersion. Always use Proglaze SSG with adequate ventilation. WARRANTY A repair or replacement warranty is available on all Tremco products. Visit https://www.tremcosealants.com/warranties/ for details. TYPICAL PHYSICAL PROPERTIES PROPERTY TEST METHOD TYPICAL RESULTS As Supplied: Flow, Sag, or Slump Inches ASTM C639 None Tack Free Time ASTM C679 10 to 15 min Tooling Time Skin Formation 5 to 10 min Ultimate Elongation ASTM C1135 193% Extrusion Rate 33 seconds Hardness (Shore A) ASTM C661 40 Maximum Elongation ASTM D412 380% Peel Strength Aluminum and Glass ASTM C794 60 lb/in Tear Strength ASTM C624 67 lb/in Tensile Strength at Max Elongation ASTM D412 350 psi As Cured, After 21 days at 77 °F (25 °C), 50%RH: Maximum Elongation ASTM D412 380% Ultimate Tensile Strength ASTM C1135 160 psi (1.10 MPa) Please refer to our website at www.tremcosealants.com for the most up-to-date Product Data Sheets. NOTE: All Tremco Safety Data Sheets (SDS) are in alignment with the Globally Harmonized System of Classification and Labelling of Chemicals (GHS) requirements. PG-SSG-DS/1222
